Product Glance | |
Out1 | |
DC Voltage | 12.0V |
Rated Current(220 V input) | 150A |
Rated Power(220 V input) | 1800W |
Rated Current(110 V input) | 83.3A |
Rated Power(110 V input) | 1000W |
Ripple & Noise | <1% |
Voltage Accuracy | 12.0-12.5V |
Line Regulation | <1% |
Load Regulation | <1% |
Setup Time | <2S |
Short Circuit Protection | >10mS |
Detailed Characteristics | |
Input | |
Voltage Range | 100-264V AC |
Frequency Range | 47-63Hz |
Power Factor | >0.99(full load) |
Leakage Current | <1.5mA(220V 50Hz) |
Protection | |
Low-voltage Input | 80-89V AC |
Output Short Circuit | Yes |
Overheat Protection | Yes |
Over-current Output | 150-200A |
Environment | |
Operating Temperature | -20-60℃ |
Operating Humidity | 0~40 |
Altitude | < 2000m |
Structure | |
Dimensions | 206*110*62mm |
Net Weight | 2.0kg |
Cooling System | Forced‐air cooling |
Noise | 43DB |
